20TS Decolorization shaker
脫色搖床廣泛應用于考馬斯藍染色和脫色時的震蕩搖晃，電泳凝膠的固定，硝酸銀染色時的固定、染色、顯彰等。
Decolorization shaker is widely used in coomassie blue dyeing and decolorization shaking, electrophoresis gel fixing, silver nitrate dyeing fixing, dyeing, development and so on.
產品特點：
1、外形精巧，節省空間，功能強大，兼容性強。
2、吸盤式機腳，超強防震，高速平穩，無噪聲。
3、超大托盤設計，放置樣品多，負重能力強。
4、三種機型可選，配置性能由低到高，滿足更多選擇。
1. Compact appearance, space saving, powerful function and strong compatibility.
2. Suction cup type machine feet, super shockproof, high speed and smooth, no noise.
3. large platform design, placing more samples, strong load capacity.
4. Three models are available, the configuration performance is from low to high, to meet more choices.
|
型號 |
OS-10T |
OS-20T |
OS-20TS |
|
轉速范圍 |
0~300rpm |
50~300rpm |
50~300rpm |
|
定時范圍 |
/ |
1min~99h59min |
1min~99h59min |
|
數碼顯示 |
/ |
時間 轉速顯示 |
時間 轉速顯示 |
|
回轉半徑 |
10mm |
10mm |
10mm |
|
最大載重 |
3Kgs |
3Kgs |
3Kgs |
|
電機參數 |
直流電機 無級調速 |
直流外轉子電機 |
直流無刷電機 |
|
托盤尺寸 |
330x430mm |
330x430mm |
330x430mm |
|
蜂鳴提示 |
無 |
有 |
有 |
|
輸入電源 |
AC110/220V,50/60Hz |
AC110/220V,50/60Hz |
AC110~220V,50/60Hz |
|
功率 |
25W |
30W |
30W |
|
熔斷器 |
250V,1A,φ5x20 |
250V,1A,φ5x20 |
250V,1A,φ5x20 |
|
外形尺寸 |
W.330xD.490xH.145mm |
W.330xD.490xH.145mm |
W.330xD.490xH.145mm |
|
凈重 |
9.5kgs |
9.8kgs |
10kgs |
|
Model |
OS-10T |
OS-20T |
OS-20TS |
|
Speed Range |
0~300rpm |
50~300rpm |
50~300rpm |
|
Time Range |
/ |
1min~99h59min |
1min~99h59min |
|
Digital Display |
/ |
Time/speed display |
Time/speed display |
|
Radius of gyration |
10mm |
10mm |
10mm |
|
Max Load Capacity |
3Kgs |
3Kgs |
3Kgs |
|
Motor Parameters |
DC motor stepless speed regulation |
DC motor stepless speed regulation |
DC motor stepless speed regulation |
|
Platform Size |
330x430mm |
330x430mm |
330x430mm |
|
Beep Alarm |
No |
Yes |
Yes |
|
Voltage |
AC110/220V,50/60Hz |
AC110/220V,50/60Hz |
AC110~220V,50/60Hz |
|
Power |
25W |
30W |
30W |
|
Fuse |
250V,1A,φ5x20 |
250V,1A,φ5x20 |
250V,1A,φ5x20 |
|
Dimension |
W.330xD.490xH.145mm |
W.330xD.490xH.145mm |
W.330xD.490xH.145mm |
|
Net Weight |
9.5kgs |
9.8kgs |
10kgs |
